One component thermal conductive gel
One component thermal conductive gel

1: Thermal conductivity coefficient 1~8.0W/m.K 2: Low viscosity, easy to apply glue, low compression force application 3. Adjustable curing time, excellent high and low temperature mechanical and chemical stability

Introduction

Thermal conductive gel is typically used in wireless modules, routers, hard disks, scanners, printers, game systems, LCDPDP televisions and displays, LED power supplies, and other industrial control equipment. Thermal conductive gel is a silicone thermal conductive product with strong plasticity. It can provide products with different extrusion rates according to the customer's use. The application process can be made into a sheet product with high compression rate or into a semi fluid state according to the customer's needs to meet the automatic dispensing process. It has an efficient thermal conductive effect and excellent caulking effect

Features

high reliability

high reliability

High thermal conductivity

High thermal conductivity

high compressibility, soft and elastic

high compressibility, soft and elastic

Natural viscosity, double-sided self-adhesive

Natural viscosity, double-sided self-adhesive

Compliant with ROHS and UL environmental requirements

Compliant with ROHS and UL environmental requirements

Application Way

Automotive Electronics Fiber optic communication equipment Netcom equipment and modules Between the heating semiconductor and the heat sink Between the battery pack and the cold plate

Application Areas

Product Data

Test itemsUnitTest ResultsTest Method
Components-Silicone & Thermal Conductive Powder-
color-PinkVisual
proportiong/ m33.02ASTM D1475
Thermal impedance℃*in 2 /W0.12ASTM D5470
Extrusion raterpm30±52.54mm 90psi
Weight loss%<0.5@200℃240H
Volume resistanceOhm cm>1*1013ASTM D257
Temperature range-40~200EN344
Minimum interface thicknessmm0.09-
Flame retardant-V-0UL 94
Thermal conductivityW/m.k3.0 ASTM D5470
