Home > Products > Thermal double-sided tape
3.0W thermal conductive silicone grease
3.0W thermal conductive silicone grease

1. Good thixotropy, easy to use, economical and practical, simple coating or sealing process; 2. Better thermal conductivity, lower evaporation loss and oil separation, and no flow at high temperatures; 3. Excellent insulation performance, non-toxic, no

Introduction

1.Used for heat conduction and dissipation of electronic components such as power amplifiers, transistors, electronic tubes, CPUs, etc

2.Installation of bases and bolts for transistors, diodes, and silicon controlled rectifiers

3.Used to form a medium for transferring heat on the heating tube. Such as irons, straighteners, heating tubes in coffee pots, etc

4.Widely used in televisions, water dispensers (ice packs), induction cookers, coffee machines, and refrigerators; Audio (power amplifier); Thermistor; Heat sink; CPU fan; Baking ovens, etc

Features

high reliability

high reliability

High thermal conductivity

High thermal conductivity

high compressibility, soft and elastic

high compressibility, soft and elastic

Natural viscosity, double-sided self-adhesive

Natural viscosity, double-sided self-adhesive

Compliant with ROHS and UL environmental requirements

Compliant with ROHS and UL environmental requirements

Application Way

Between semiconductor and heat sink Between CPU and heatsink Between the power resistor and the base Thermoelectric cooling device Temperature regulator and assembly surface

Application Areas

Product Data

Project

Unit

Environment

Test Method

Test Results

color

-

25℃

Visual

gray/gray

Thermal impedance

℃-in2/W

25℃

ASTM D1470

<0.103

proportion

-

25℃

ASTMD1475

>2.5

Evaporation

%

150℃/24Hours

Fed.Std.791

<0.001

Oil separation

%

150℃/24Hours

Fed.Std.791

<0.05

Insulation Constant

-

100Hz

ASTM D150

>5

Viscosity

-

25℃

-

No flow

Cone penetration

1/10 mm

25℃

GB/T-269

410±10

Instant temperature resistance

-

-

-50~330℃

Operating temperature range

-

-

-40~200℃

Thermal conductivity

W/m.k

-

ASTM D5470

> 3.0
